Detailed Product Description
| Place Of Origin: | Shenzhen, China (Mainland) | Material: | Optical Glass, Customer Design |
|---|---|---|---|
| Size: | Customer Size | Process: | IAD Hard Coating |
| Substrate: | Optical Glass Or Customer Design | Size(mm): | Custom |
| Surface Quality: | Customer Design |
700-1100nm Nano Multicoated Graduated IR Neutral Density Glass
Optical performance index:
Transmission Range:700-1100nm
Transmission:T=75%,±3%
UV: 250nm~380nm,cut20%,50%.
vis:400nm~700nm ,cut99%,90%,80%,70%,50%,30%,20%,10%
VIS NIR:400nm~1000nm ,cut OD=0.5,OD=1,OD=2,OD=3,OD=5,OD=10,OD=20,OD=30
1200nm,1310nm,1550nm,T=70%,20%,50%,1%,ect
CWL:700nm±10nm
Blocking:T<2%
Application :
UV instrument
optical laser
optical digital camera,video camera,security camera
optical equipment
optical communication attenuation filters
