Detailed Product Description
Product Name: | Silicon Optical Components | Material: | Silicon / Germanium |
---|---|---|---|
Surface Quality: | 60-40 | Dimension Tolerance: | +0.0 / -0.20 |
Design Wavelength DWL (nm): | 3-5μm | Center Thickness Tolerance(mm): | 0.1 |
Germanium Optical Components Silicon infrared lenses for NIR Imaging
Silicon Optical Components
Specifications:
Numerical Aperture NA | 0.28 |
Diameter (mm) | 30.00 |
Diameter Tolerance (mm) | +0.00/-0.10 |
Effective Focal Length EFL (mm) | 40 |
Focal Length Tolerance (%) | ± 1.5 |
Alignment Wavelength (nm) | 1.78 |
Clear Aperture CA (mm) | 22.5 |
Back Focal Length BFL (mm) | 29.38 |
Back Focal Length BFL from Housing (mm) | 22.38 |
Spot Size (um) | <Diffraction Limit |
Chromatic Correction Wavelength (um) | 3 – 5 |
Coating Specification | Ravg<3.0% @ 3 – 5um |
Chromatic Focal Shift (um) | <12 |
Design Wavelength DWL (um) | 4 |
Coating | 3 – 5um |
Substrate | Silicon / Germanium |
Housing Length (mm) | 17.90 |
Type | Achromatic Lens |
Length Tolerance (mm) | ± 0.10 |
Wavelength Range (um) | 3 – 5 |
RoHS | Compliant |
Description:
Silicon Optical Components are used in a variety of infrared applications operating in the 1.2 – 7μm wavelength range, including NIR imaging or IR spectroscopy. Silicon’s low density (2.329 g/cm3) is ideal for use in weight-sensitive applications. Silicon features a Knoop hardness of 1150, making Silicon Optical Components harder, less brittle alternatives to comparable Germanium Optical Components.
GIAI Optics features a wide variety of Silicon Optical Components, including optical lenses, optical filters, or windows. Silicon optical lenses are ideal for collimation or focusing applications that utilize
monochromatic light. These lenses are available in a range of sizes or focal lengths for a wide variety of application needs. Silicon lens kits are also available. Silicon optical filters, which are integrated into IR applications such as FTIR spectroscopy, are used to transmit or block a specific range of IR wavelengths. Silicon windows are available uncoated or with a 3 – 5μm antireflection coating.
Infrared (IR) Achromatic Lenses are ideal components for designers and researchers working in the 3-5um spectral region. Designed to provide near diffraction-limited performance over their full spectral range, our lenses are ideal for applications in FTIR Spectroscopy, Thermal Imaging, and for use with tunable QCL Lasers. The lenses provide significantly improved performance versus comparable singlets, allowing designers in industrial, medical, scientific, and military applications to use the full dynamic range and quantum efficiency of their mid-wave sensors.
Competitive Advantage:
Silicon Lenses ,competitive price , good quality, delivery on time, providing perfect after-sales service, to provide customers with professional customized products of parameter. We will supply you with best solution.
